V Groove Cutting Saw UPVC Window Machine With 0.5-0.8 MPa Air Pressure

Model Number : LJVW-65

Certification : CE ISO

MOQ : 1set

Price : By negotiation

Supply Ability : 30 sets per month

Delivery Time : 20 days

Packaging Details : 1, plastic stretch film coating; 2, steel pallet and plywood case package; 3, LCL or FCL by sea transportation;

Function : Window V notch Cutting Saw

Air pressure : 0.5-0.8MPa

Rotating rate : 2800r/min

Cutting height : 60mm

Total power : 1.5Kw

Product : Plastic PVC Window Making Machine Window V notch Cutting Saw

Contact Now

V-notch Cutting Saw PVC and Aluminum Windows Making Machine / UPVC Window Frame V Cutting Machine for Aluminum Profile

Product parameter

PVC profile V cutting saw is used for 90 degree V groove cutting on profiles. Profiles are clamped and cut by pneumatic drive, which ensure easy operation, safety, precise cutting and convenient maintenance.Adopts industry grade computer system, closed-loop controlled, the user can set the processing parameters according to profile, the cutting size shift quickly, locating precision high, the repeat locating precision is ±0.1mm.High precision linear guiding pair ensured steady and long-term processing accuracy.Adopt imported air-hydraulic conversion device, so that ensure running stably.Stability high precision machine body, the design of machine body conform to the aesthetic point and human body engineering principle.

Power	1.5kw
Voltage	380V/50HZ
Air pressure	0.4-0.8MPa
Rotation rate	2800r/min
Saw size	D=300mm d=30mm
Cutting height	0-60mm

Product Display

V Groove Cutting Saw UPVC Window Machine With 0.5-0.8 MPa Air Pressure

Product detail

V Groove Cutting Saw UPVC Window Machine With 0.5-0.8 MPa Air Pressure
